Welcome, Event Visionaries!

Are you ready to transform your trade show presence into something spectacular? Whether you’re hosting a product demo, DJ set, or dazzling exhibit, the Global Truss F34 10x29 ft Trade Show Booth is your ultimate solution. It’s versatile, professional, and designed to turn heads at any event. Let’s dive into assembling this show-stopping structure with ease and flair.

Why Choose This Booth?

This booth combines sleek design with unparalleled strength. Crafted from durable aluminum trusses, it’s lightweight yet robust, ensuring it holds up through the hustle and bustle of any event. Perfect for:

• Trade show booths

• DJ lighting truss systems

• Convention booth trusses

• Portable stages

• Display booth trusses


What You’ll Need to Build It

Every component you need is available at famousstages.com, the trusted source for all your stage trussing and lighting trussing needs:

1. 8 x Global Truss F34 Box Truss 8.2 ft long (vertical posts)

2. 2 x Global Truss F34 Box Truss 7.38 ft long (horizontal width)

3. 2 x Global Truss F34 Box Truss 7.38 ft long (middle beams)

4. 6 x Global Truss F34 Box Truss 8.2 ft long (horizontal length)

5. 8 x Global Truss F34 ST-UJB-12 (corner + middle connectors)

6. 8 x Global Truss F34 Box Truss SQ-4137 Base Plates


Step 1: Set the Foundation

Start by placing the eight SQ-4137 Base Plates to define the booth’s footprint. Position four at the corners and the remaining four for the center posts along the longer sides of the booth. This layout creates a sturdy foundation for the trusses to stand tall.

Step 2: Assemble the Vertical Posts

Attach eight 8.2 ft Global Truss F34 Box Trusses to the base plates. These posts will act as the booth’s sturdy pillars, giving it height and presence. Secure ST-UJB-12 Junction Blocks at the top of each vertical post to prepare for the horizontal trusses.

Step 3: Build the Horizontal Lengths (Front and Back)

Using six 8.2 ft Global Truss F34 Box Trusses, connect the tops of the vertical posts to form the front and back horizontal lengths. These 29-foot-long sides will define the booth’s length and provide ample space for lighting trussing or branding elements.

Step 4: Connect the Horizontal Widths (Left and Right)

Attach the 7.38 ft Global Truss F34 Box Trusses to connect the left and right sides of the booth. These sections complete the rectangular frame and add structural stability to the setup.

Step 5: Install the Middle Beams

Add the two 7.38 ft middle beams between the center vertical posts on the longer sides. These beams provide extra support for the overall structure and divide the space into three sections, offering versatility for different setups, like lighting trussing or hanging displays.

Step 6: Customize Your Booth

With the frame complete, it’s time to make the booth your own. Whether you’re adding DJ lighting truss systems, creating an interactive trade show display, or setting up a portable stage, the possibilities are endless. Let your creativity shine and build a booth that’s as unique as your vision!

Why Famous Stages?

At famousstages.com, we’re your go-to destination for everything truss-related. From stage trusses to aluminum lighting trusses, we offer:

• Durability: Built for heavy-duty use at any event.

• Portability: Lightweight and easy to transport.

• Versatility: Ideal for trade shows, conventions, and more.


Take Your Event to New Heights

Ready to make your trade show booth the talk of the town? Visit famousstages.com today and explore our full range of lighting trusses, stage trussing systems, and more.

This 10x29 ft trade show booth is more than just a structure; it’s a statement. Let’s make yours unforgettable!

Welcome, Event Enthusiasts!

If you're looking to elevate your event space with a professional, reliable, and versatile setup, you’re in the right place. Today, we’ll guide you through building a Global Truss F34 10x20 ft Trade Show Booth with Center Posts and Top Beam – a perfect solution for trade shows, conventions, DJ setups, and more.

With stage trussing designed for durability and elegance, this booth not only stands out but also adapts seamlessly to any event. Whether you need a lighting truss for stunning effects or a robust structure for displays, this setup has you covered!

Why This Setup Rocks

This stage truss system combines strength and lightweight aluminum truss construction, making it ideal for:

• Trade show booths
• DJ lighting truss systems
• Convention booth trusses
• Portable stages
• Display booth trusses

Let’s build a booth that attracts crowds and leaves a lasting impression!

What You’ll Need

Get everything you need at famousstages.com, your one-stop shop for lighting trussing, stage trusses, and more:

1. 6 x Global Truss F34 Box Truss 8.2 ft long (vertical posts)
2. 2 x Global Truss F34 Box Truss 7.38 ft long (horizontal width)
3. 1 x Global Truss F34 Box Truss 7.38 ft long (center beam)
4. 4 x Global Truss F34 Box Truss 8.2 ft long (horizontal length)
5. 6 x Global Truss F34 ST-UJB-12 (corner + middle connectors)
6. 6 x Global Truss F34 Box Truss SQ-4137 Base Plates

Step 1: Lay the Foundation

Position six base plates to mark the corners and center posts. These aluminum lighting trusses are lightweight yet incredibly strong, making assembly a breeze and ensuring stability.

Step 2: Build the Vertical Posts

Attach the 8.2 ft long aluminum trusses to the base plates. These stage trusses create six vertical posts: four at the corners and two in the middle.

Secure the ST-UJB-12 universal junction blocks to the top of each vertical post. These will connect the front and back horizontal trusses, left and right sides, and the center beam, ensuring maximum stability and flexibility for your trade show booth.

Step 3: Connect the Front and Back Horizontal Length

Using 8.2 ft long trusses, assemble the 20-foot-long front and back horizontal sides. These lighting trusses provide a solid frame, offering an excellent spot for hanging banners, lights, or other decorative elements.

Step 4: Attach the Left and Right Horizontal Width

Connect the shorter 7.38 ft aluminum trusses to form the 10-foot-wide left and right sides. The lightweight yet sturdy design ensures your display booth truss maintains its integrity while staying portable.

Step 5: Add the Center Beam

To finalize the frame, attach the 7.38 ft center beam between the middle vertical posts. This DJ truss not only reinforces the booth but also creates a natural division into two square sections. Use this beam to hang additional lighting or decor.

Step 6: Customize and Shine

Your booth is ready, but the fun isn’t over! Add portable stages, hang dazzling lighting trussing, or set up your complete DJ lighting truss system to create an unforgettable event experience. The versatility of Global Truss systems ensures professionals always have a reliable solution.

Why Choose Famous Stages?

At famousstages.com, we offer everything from display booth trusses to portable stage solutions. Our Global Truss products are trusted by professionals for being:

• Durable: Engineered for heavy-duty use.
• Portable: Lightweight and easy to transport.
• Versatile: Perfect for stage trussing, convention booth trusses, and more.

Unlock the Potential of Your Booth

Ready to transform your event presence? Head over to famousstages.com and explore our full range of stage trusses, lighting trusses, and trade show display systems.

This 10x20 ft trade show booth is more than just a setup – it’s a statement. Make yours today and become the star of the show!

🎉 Your journey to event greatness starts here! 🎉

Looking to add a professional, eye-catching setup to your stage, DJ booth, or trade show display? Look no further! The Global Truss F34 10x10-ft Goal Post System with Rounded Corners is a sleek, reliable solution perfect for anyone needing a robust trussing setup. Whether you’re a DJ, event manager, or venue owner, this system will give your lighting, sound, and video displays a standout presence.

Let’s dive into how this setup comes together and why it’s an essential investment for anyone who values quality and aesthetics.

Unboxing Your Global Truss F34 10x10-ft Goal Post Package

Here’s what you get when you order the complete package:

• 1 x Global Truss SQ-4112 - 6.56 ft long F34 Square Truss Segment
• 2 x Global Truss SQ-4113 - 8.2 ft long F34 Square Truss Segments
• 2 x Global Truss 1' x 4' Base Plates - Provides stable foundations for the vertical trusses
• 2 x Global Truss SQ-4121-CR-L90 - 90-degree 2-Way Rounded Corners to create that professional, sleek look.

With these components, you’ll build a stunning 10x10 goal post that’s sturdy, easy to set up, and guaranteed to impress any audience.

Step-By-Step Guide to Building Your 10x10 Goal Post Truss

Step 1: Setting the Foundation

Start with your two 1’ x 4’ Base Plates. Place them on the ground about 10 feet apart. Make sure they’re on a flat, solid surface to ensure your truss structure is stable and secure. These heavy-duty base plates are the backbone of the system, providing solid support for the vertical trusses.

Step 2: Building the Vertical Support

Now, take the two 8.2 ft Global Truss SQ-4113 F34 Square Truss Segments. Attach each one vertically to the base plates using the secure couplers and pins connection system provided. Ensure the bolts are tightened snugly to keep the trusses locked in place—loose bolts could compromise the safety and stability of your structure.

By now, you should have two impressive 8.2-foot-tall truss pillars standing sturdy on their base plates, ready to support your lighting, video, or sound gear.

Step 3: Adding the Rounded Corners

This is where the SQ-4121-CR-L90 90-degree Rounded Corners come into play. These corners not only add a professional touch to your setup but also ensure that cables and lights have an easy transition around corners, making your rig look cleaner and more organized. Attach a rounded corner to the top of each vertical truss post using the convenient spigot connectors.

The rounded corners give the goal post a smooth, sophisticated finish, ideal for any event space—whether it’s a trade show, DJ booth, or stage performance. The sleek curves are sure to catch the eye of anyone passing by!

Step 4: Completing the Horizontal Connection

Finally, connect the two rounded corners with the 6.56 ft Global Truss SQ-4112 F34 Square Truss Segment. This piece forms the horizontal beam that completes the 10x10 goal post. Make sure all connections are tight and secure.

Congratulations! You’ve just completed the assembly of the Global Truss F34 10x10-ft Goal Post System. All that’s left is to hang your lights, LED panels, or any additional elements to make your event unforgettable.

Why Choose the Global Truss F34 10x10-ft Goal Post?

• Durability and Stability: The F34 series is crafted from high-grade aluminum, making it lightweight yet incredibly strong. Perfect for handling heavy lighting and video equipment without breaking a sweat.
• Sleek and Professional Design: The rounded corners give a polished, clean look, setting you apart from competitors who might use plain, sharp-angled trusses.
• Versatile Application: Use it for DJ setups, trade show booths, stages, lighting trusses, or any event where you need a rock-solid structure that also looks fantastic.
• Easy to Assemble: The intuitive bolt and connector system makes setup quick, allowing you to spend more time focusing on the event itself.

Real-World Applications of the Global Truss F34 10x10 Goal Post with Rounded Corners

Need inspiration? Here are some creative ways to use this versatile truss system:

1. DJ Booth: Elevate your DJ setup with hanging lights and speakers that transform the dance floor into an electrifying space.
2. Stage Performances: Perfect for small to medium-sized events, providing a structured lighting framework that brings performances to life.
3. Trade Shows and Conventions: Ideal for creating an eye-catching booth that stands out from the crowd. Hang banners, signage, or digital displays for maximum visibility.
4. Portable Stages: This truss system is easy to transport and assemble, making it a fantastic choice for mobile stage companies.

Why Famous Stages Is Your Go-To for Truss Systems

At Famous Stages, we understand the needs of the professional and enthusiast alike. We offer only the best in lighting trusses, DJ trussing, and stage truss systems, ensuring you have the tools you need to put on an unforgettable show. Our Global Truss F34 10x10-ft Goal Post System with Rounded Corners isn’t just another truss—it’s a game-changer for your stage setup.

Ready to Take Your Stage to the Next Level?

Invest in the Global Truss F34 10x10-ft Goal Post System today and experience the difference that top-quality stage trussing can make. Head over to famousstages.com to browse our full selection of aluminum lighting trusses, portable stages, and more.

Don’t just blend in—stand out with a professional, sleek setup that will leave a lasting impression. Ready to build? We’ve got you covered!

If you're an event or production manager, you know the importance of a reliable, eye-catching, and professional truss system. Today, we’ll guide you through assembling a 20x20 ft Global Truss F34 Booth Truss with Rounded Corners using a selection of quality truss materials designed for durability and aesthetics. This booth setup is ideal for conventions, trade shows, stage events, or DJ gigs. Let’s dive into this step-by-step guide that’ll make your setup a breeze and showcase why investing in aluminum truss systems is the right move.

Materials You’ll Need

• 2 pcs. Global Truss SQ-4113 8.2' ft. F34 Square Truss Segments (Top Back Side)
• 4 pcs. Global Truss SQ-4113 8.2' ft. F34 Square Truss Segments (Top Left Side: 2 pcs., Top Right Side: 2 pcs.)
• 4 pcs. Global Truss SQ-4113 8.2' ft. F34 Square Truss Segments (Vertical Posts)
• 4 pcs. Global Truss SQ-4137 1' x 1' Base Plates
• 2 pcs. Global Truss SQ-4126-CR-L90 90-deg. 3-Way Rounded Corners (For Top Back Corners)
• 2 pcs. Global Truss SQ-4121-CR-L90 90-deg. 2-Way Rounded Corners (For Top Front Corners)

Step 1: Prepare the Base for Stability

Let’s start with the foundation of your truss system. The Global Truss SQ-4137 1’ x 1’ Base Plates are the key to ensuring that your booth is rock-solid. Place all four base plates on the ground in a square layout, ensuring they are positioned 20 feet apart, creating the base footprint of your truss booth.

Step 2: Setting Up the Vertical Posts

Now, it’s time to install the vertical posts. For this, you’ll need the four Global Truss SQ-4113 8.2 ft. Square Truss Segments:

1. Connect each truss segment to a base plate using the appropriate connector couplers and pins.
2. Ensure all four trusses stand vertically at the corners of the 20x20 ft space.
3. Use a spirit level to make sure they’re straight. The stability here is crucial, as these vertical trusses will support the entire structure.

Step 3: Building the Upper Frame - Rounded Corners for a Sleek Look

Now that your vertical posts are secure, it’s time to assemble the upper frame, which will give your booth its distinctive rounded corner look.

1. Start with the back side of the booth:
• Use two Global Truss SQ-4113 8.2 ft. Truss Segments for the top back side.
• Connect each end of the back truss to a Global Truss SQ-4126-CR-L90 3-Way 90-Degree Rounded Corner. These corners will secure the top back segment to the vertical posts.
2. For the front corners, you’ll use two Global Truss SQ-4121-CR-L90 2-Way 90-Degree Rounded Corners. These rounded corners will be connected to the vertical posts at the front.

Step 4: Complete the Upper Structure

Next, you’ll need to complete the sides of the top frame:

1. For the left and right sides, use four Global Truss SQ-4113 8.2 ft. Truss Segments:
• Two segments per side will connect the back corners to the front rounded corners.
• Attach securely using the rounded corners and ensure everything is tightened down.
2. Double-check all connections with a hex wrench to ensure no bolts are loose.


Step 5: Lifting the Upper Frame

This step will require a few helping hands:

1. With the top frame fully assembled on the ground, get a team to carefully lift the entire upper structure.
2. Align it with the tops of the vertical posts.
3. Secure each end to the top of the vertical posts, using connector bolts.

Step 6: Final Adjustments and Safety Checks

With everything in place, give the booth a thorough inspection:

• Ensure all connections are tight.
• Double-check that the structure is level and stable.
• Add any optional lighting truss or stage equipment for a fully customized look.

Why Choose a Global Truss System with Rounded Corners?

Rounded corners not only look modern and sleek, but they also provide enhanced stability by distributing weight more evenly throughout the structure. This truss system is a top choice for portable stages, DJ booths, and trade show displays, thanks to its lightweight yet robust aluminum truss build.

Optimize Your Event with Global Truss F34

By investing in this truss setup, you’re getting more than just a sturdy frame—you’re getting a versatile platform for all your lighting, branding, and display needs. The Global Truss F34 is known for its strength and durability, making it perfect for repeated use in a variety of events, from corporate trade shows to high-energy DJ performances. The addition of rounded corners adds a professional touch, making your booth stand out from the competition.

Where to Buy Your Global Truss F34 Booth System

Ready to take your event production to the next level? Famous Stages offers all the components you need to create the perfect lighting truss system. Whether you’re looking for a stage truss, DJ trussing, or a customizable convention booth, you’ll find the best selection of truss equipment here. Don't settle for anything less than the industry standard—choose Global Truss for a flawless, reliable setup every time.

When it comes to creating a professional, visually striking setup for events, a Global Truss booth with rounded corners is a fantastic choice. Whether you’re setting up for a DJ truss display, stage trussing for performances, or a sleek convention booth truss at a trade show, this 10x20 ft booth offers versatility and style.

If you’re looking to grab attention with a sturdy aluminum truss setup that is as functional as it is impressive, this guide will walk you through assembling this display booth truss package. Not only will this truss system add a touch of class, but it’s also highly durable, making it perfect for portable stages, lighting setups, and trade shows alike. Let’s dive in and get this stage truss structure ready to shine!

Package Contents

For this build, here’s what you’ll be working with:

• 2 pcs. Global Truss SQ-4112 6.56 ft long F34 Square Truss Segments (top left and right sides)
• 2 pcs. Global Truss SQ-4113 8.2 ft long F34 Square Truss Segments (back side of the top structure)
• 4 pcs. Global Truss SQ-4113 8.2 ft long F34 Square Truss Segments (vertical posts)
• 4 pcs. Global Truss SQ-4137 1 ft x 1 ft Base Plates (for a sturdy foundation)
• 2 pcs. Global Truss SQ-4126-CR-L90 90° 3-Way Rounded Corners (back top corners)
• 2 pcs. Global Truss SQ-4121-CR-L90 90° 2-Way Rounded Corners (front top corners)

With these components, you’ll build a top-notch lighting truss or dj lighting truss that’s built to last!

Step 1: Setting Up the Foundation

Start by laying out your four base plates (SQ-4137) in a 10x20 ft rectangular layout. These base plates will anchor your aluminum lighting truss system securely to the ground, so make sure they’re spaced evenly. This setup is ideal for portable stages or any display booth truss where stability is key.

Attach an 8.2 ft SQ-4113 truss segment to each base plate to form the vertical posts. These four posts will give your booth structure height, making it perfect for lighting setups or dj truss configurations at events. You’re already halfway to an eye-catching stage truss!

Step 2: Building the Top Horizontal Frame

Now for the top frame, which will be the main horizontal structure of your lighting trussing.

1. Front Left Side: Begin by connecting a 90° 2-Way Rounded Corner (SQ-4121-CR-L90) to the top of the front left vertical post. Attach a 6.56 ft SQ-4112 truss segment to this rounded corner.

2. Back Left Side: At the end of the 6.56 ft segment, connect a 90° 3-Way Rounded Corner (SQ-4126-CR-L90). This rounded corner will let you attach the back truss segments perpendicularly, giving the convention booth truss more depth.

3. Back Side: Now, attach the two 8.2 ft SQ-4113 truss segments to connect across the back of the structure, forming the back side of your booth’s top frame.

4. Back Right Side: Connect another 90° 3-Way Rounded Corner (SQ-4126-CR-L90) to the end of the back truss segments.

5. Front Right Side: Complete the frame by attaching a 6.56 ft SQ-4112 truss segment to this rounded corner, then finish off by connecting a 90° 2-Way Rounded Corner (SQ-4121-CR-L90) at the top of the front right vertical post.


This creates a solid rectangular frame with rounded corners for a polished, high-end look that’s ideal for stage trussing at any event.

Step 3: Connecting the Top Frame to the Vertical Posts

With the top frame assembled, it’s time to lift it onto the vertical posts.

1. Position each corner of the top frame above the corresponding vertical post.
2. Secure each corner rounded truss connector to the top of each vertical post. The rounded corners provide seamless connections while giving the entire stage truss structure a streamlined appearance.

Step 4: Securing Connections and Final Touches

Before declaring victory, go around the entire structure to check that every connection is tight and secure. This final step is crucial, especially if your booth will be supporting lights, speakers, or other equipment for a dj lighting truss setup or lighting truss.

With everything locked down, you’re ready to go! Take a step back and admire your professional-grade Global Truss booth, which now stands as a show-stopping convention booth truss.

Why Choose Famous Stages for Your Truss Needs?

Our Global Truss F34 systems are built for reliability and durability, with a smooth, rounded-corner design that makes a lasting impression. The versatility of this aluminum truss system is ideal for anything from display booth truss setups to portable stages and lighting trussing solutions. At famousstages.com, we’re here to make sure your truss setup is easy to assemble, affordable, and ready for the spotlight.

Make your next event unforgettable – check out famousstages.com for unbeatable deals on truss systems that are built to impress!

Whether you’re setting the stage for a live DJ performance, showcasing the latest lighting effects, or creating an eye-catching trade show booth, a Global Truss 10x10 F34 Goal Post is the perfect solution! With just a few materials, you’ll be able to build a sturdy, reliable structure that enhances your display and keeps everything supported securely. Ready to go? Let’s dive into this quick and easy assembly.

Materials Needed:

• 2 x ST-UJB-12 Universal Junction Block (for corner connections)
• 2 x SQ-4112-275 9.02-Ft Truss Segments (vertical posts)
• 1 x SQ-4113 8.20-Ft Truss Segment (horizontal crossbar)
• 2 x BASE PLATE 1.4S 12" x 48" Steel Base (for a stable foundation)

This Global Truss F34 setup offers impressive versatility and is a favorite for creating lightweight but highly durable structures at all types of events. With a little help from these trussing components, you’re ready to set the stage!

Step 1: Setting Up the Base Plates

To start, position your 2 BASE PLATE 1.4S Steel Bases exactly where you want the vertical posts to stand. These heavy-duty base plates provide a sturdy, stable foundation essential for holding up the entire structure, so make sure they’re firmly placed and aligned 10 feet apart from each other.

These steel base plates make this goal post ideal for indoor and outdoor use, whether it’s supporting lighting truss at a DJ booth or acting as an anchor for a trade show banner. You’re already setting the stage for a successful event!

Step 2: Attaching the Vertical Trusses

Now, it’s time to set up the vertical posts. Take each of your SQ-4112-275 9.02-ft truss segments and attach them to the base plates. These trusses will serve as the vertical sides of your goal post, providing the height and presence your display needs.

• Make sure the trusses are securely connected to the base plates. A tight, stable connection here is essential for the overall sturdiness of the structure.
• With the 9.02-ft trusses in place, you’ll have two solid verticals standing tall, waiting for the top bar to tie it all together.

Step 3: Connecting the Top Crossbar

Now that you have your vertical posts in place, it’s time to install the horizontal crossbar. For this, you’ll need the SQ-4113 8.20-ft truss segment and the ST-UJB-12 Universal Junction Blocks.

1. Start by attaching an ST-UJB-12 junction block to the top of each vertical post. These universal junction blocks make it easy to secure the horizontal truss to the two vertical trusses.
2. Next, take your 8.20-ft truss segment and connect it horizontally between the two junction blocks.

This crossbar will provide the perfect support for lights, banners, or even a lighting trussing system for dramatic visual effects. Once connected, double-check the stability of the trusses and junction blocks to ensure everything is locked in tight.

Step 4: Final Adjustments and Securing the Structure

With the frame now assembled, it’s time for a few last-minute checks to ensure the structure is solid.

1. Ensure that the base plates are level and securely anchored to the ground.
2. Check each truss connection to make sure everything is tight and stable.
3. If you’re planning on adding equipment, confirm that the goal post truss system can handle the load.

The Global Truss F34 system is known for its durability and strength, making it ideal for supporting lighting truss setups, DJ gear, or branding materials. This stage truss system should feel sturdy, standing 10 feet tall and 10 feet wide, and should be able to handle everything from banners to lighting effects with ease.

Why Choose the Global Truss F34 System for Your Goal Post?

The Global Truss F34 system is trusted by event managers, production professionals, and DJs worldwide because of its strength, portability, and quick assembly. Built from lightweight aluminum, this aluminum truss is easy to transport while being tough enough for demanding applications. This setup is perfect for creating an impactful entranceway, framing a DJ trussing area, or setting up a professional stage trussing system.

The 10x10 goal post configuration is not only versatile but also allows you to add additional trussing segments or accessories, making it adaptable for various events and setups.

A Truss System Built for Success

With your Global Truss 10x10 F34 Goal Post assembled, you’re ready to go! This strong, portable frame is an essential tool for any professional looking to set up quickly, reliably, and with impressive visual impact.

For all your stage truss, lighting trussing, and display booth truss needs, remember to check out famousstages.com. Your next event deserves the best, and with the Global Truss F34, you’ll be set to make a memorable impression every time.

Shout out and If you’re ready to impress at your next event, the Global Truss 10' x 40' Display Booth Truss System with a center beam is the setup you need. Whether you’re showcasing your products at a trade show or setting the stage for a killer DJ performance, this truss system is the ideal choice for versatility and durability. And don’t worry—it’s easy to assemble! Let’s get this show on the road.

Materials You’ll Need:

• 6 x Global Truss F34 Box Truss 8.2 ft long (Vertical posts)
• 2 x Global Truss F34 Box Truss 7.38 ft long (Horizontal width)
• 1 x Global Truss F34 Box Truss 7.38 ft long (Center beam)
• 8 x Global Truss F34 Box Truss 9.02 ft long (Horizontal length)
• 6 x Global Truss F34 ST-UJB-12 Junction Blocks (4 corners + 2 middle connectors)
• 6 x Global Truss F34 SQ-4137 Base Plates

Step 1: Setting the Base – Base Plates and Vertical Posts

Begin by placing your SQ-4137 base plates in position to form the 10-foot by 40-foot footprint of your display booth. Place 4 base plates at the corners and 2 in the middle along the long sides, spaced evenly at 20 feet.

Now, attach the 6 vertical posts using the Global Truss F34 Box Truss 8.2 ft long segments. These will form the supporting pillars of your structure. Each vertical post is secured to the base plates, giving you the backbone for your truss system.

Step 2: Building the Long Sides – Horizontal Length Trusses

Let’s tackle the long sides first. For each 40-foot side, you’ll need to follow this sequence:

1. Start by attaching a Global Truss F34 ST-UJB-12 Junction Block at the top of one of the corner vertical posts.
2. Then, connect a Global Truss F34 Box Truss 9.02 ft long to the junction block.
3. Add another 9.02 ft truss to reach the middle of the long side, where you’ll attach another ST-UJB-12 junction block.
4. Repeat the process by connecting the second set of 2 x 9.02 ft trusses to extend the long side up to the next corner junction block.

So, each long side of your booth is connected like this:
ST-UJB-12 (corner) + 2 x 9.02 ft Box Trusses + ST-UJB-12 (middle) + 2 x 9.02 ft Box Trusses + ST-UJB-12 (corner).

Repeat the process for the other 40-foot long side.

These connections form the strong horizontal beams, giving the booth excellent stability and making it a solid foundation for hanging lighting or banners. The stage trussing on these long sides is key to supporting any equipment you plan to display.

Step 3: Connecting the Short Sides – Horizontal Width Trusses

Next, let’s move to the short sides. For the front and back widths of the booth, you’ll be using the 2 x Global Truss F34 Box Trusses (7.38 ft long).

1. Attach the 7.38 ft trusses to the ST-UJB-12 junction blocks at the front and back corners to form the short left and right sides, completing the rectangular frame.
2. The width trusses will give the booth a strong, defined shape, ensuring that everything is connected securely for maximum stability.

Step 4: Installing the Center Beam – Adding Extra Support

Now, it’s time to install the center beam. This is what will add that extra level of stability to your truss system, especially if you’re planning to hang lighting trusses or other equipment.

1. Take the remaining Global Truss F34 Box Truss (7.38 ft long) and attach it between the two middle vertical posts using the ST-UJB-12 junction blocks on top of the posts.
2. The center beam will run parallel to the width trusses, acting as the backbone for additional structural support.

Step 5: Securing and Final Adjustments

Once all the trusses are connected and your Global Truss 10' x 40' Display Booth is standing tall, it’s time to secure everything in place. Double-check all the junction block connections to ensure they’re tight and solid.

Give the structure a little shake test—if everything feels firm and sturdy, you’re good to go. The stage trussing should feel secure, especially along the long sides where the center beam provides extra reinforcement.

Why Choose the Global Truss F34 System?

The Global Truss F34 system is an industry favorite for a reason. It’s built from lightweight, high-strength aluminum, making it perfect for traveling from event to event without breaking a sweat. Whether you need a lighting truss, a display booth, or a DJ trussing setup, the F34 system is modular, durable, and designed for easy assembly and disassembly.

The modular nature of this truss system means you can mix and match different configurations, making it the perfect solution for events of all sizes. Plus, it’s strong enough to hold lighting, banners, and even heavy-duty equipment, making it the go-to choice for professionals in the industry.

Final Thoughts

You’ve now assembled a spectacular 10' x 40' display booth that’s ready to dazzle at your next event. Whether you’re setting up at a convention, trade show, or concert, this Global Truss F34 system will ensure your booth stands out.

For all your stage trussing, lighting truss, and display booth needs, be sure to check out famousstages.com for the best selection of trussing systems. With the right truss setup, your event is bound to be a success!

The Ultimate Guide to Setting Up Your Event’s Centerpiece

If you’ve ever been to a live event or show and marveled at the seamless setups, sleek lighting rigs, and stunning displays, there’s a good chance you were gazing at a Global Truss system in action. Today, I’m going to walk you through erecting a Global Truss F33 10x10-ft Triangle Goal Post System, which is perfect for stages, DJ setups, or trade show booths.

The great thing about this 10x10-ft Triangle Goal Post is that it’s not only versatile but also super easy to assemble—even if you’ve never done it before. And trust me, once you see it in action, you’ll understand why it’s a must-have in the event industry.

What’s in the Box?

Before we jump into the build, let’s go over the components that’ll bring this baby to life:

• 2 x Global Truss TR-4088-I Corner Pieces
• 1 x Global Truss TR-4079 6.56' Triangle Truss Segment (horizontal beam)
• 2 x Global Truss TR-4080 8.2' Triangle Truss Segments (vertical posts)
• 2 x Global Truss 1x4-ft Steel Base Plates

These sturdy components come together to form a rock-solid goal post structure, ideal for hanging lighting trusses, banners, video screens, or even a slick entrance arch.

Step 1: Set the Foundation with Global Truss Base Plates

You’ve got your steel Global Truss 1x4-ft BASEPLATES laid out in front of you, which are the foundation of your system. These hefty plates provide stability and ensure your truss stands firm, no matter how much equipment you hang from it.

Place both base plates 10 feet apart. Make sure they’re aligned and secure on a flat surface. Whether you’re indoors or outdoors, these steel bad boys will keep your setup from wobbling.

Step 2: Assemble the Vertical Posts

Next, grab the Global Truss TR-4080 8.2' Triangle Truss Segments. These two pieces will be your vertical posts. Using the Global Truss TR-4088-I Corner Pieces, attach the bottom of each vertical post to the base plates. The corner pieces give a solid connection point and ensure the structure remains sturdy.

You’ll want to ensure everything is nice and snug here because the vertical posts are going to support most of the weight when you attach the horizontal beam. Double-check your connections—it’s always better to be safe than sorry!

Step 3: Attach the Horizontal Beam

Now comes the fun part. Take the Global Truss TR-4079 6.56' Triangle Truss Segment and attach it horizontally across the top of the two vertical posts. This is where the magic happens—your structure is coming together!

Make sure to carefully align the ends of the horizontal beam with the top of the vertical posts, using the Global Truss TR-4088-I Corner Pieces to secure everything in place. If you’ve got an extra pair of hands or a couple of step ladders, this part will be a breeze.

This truss beam is where you’ll hang your lights, video screens, banners, or whatever else you have in mind. The triangular design provides superior strength, allowing you to load it up without worrying about sagging or bending.

Step 4: Secure & Final Adjustments

Once everything is connected and standing tall, give it all a once-over. Tug on the connections to make sure nothing’s loose, and make any final adjustments to the placement. It’s always a good idea to level everything out, especially if you’re setting up on uneven ground.

Pro tip: If you’re using this for a stage, concert, or event, make sure to test out any hanging equipment or Global Truss lighting trusses before the big day. You want to ensure your truss can handle the load you plan to put on it.

Ready, Set, Shine!

And just like that, you’ve erected your Global Truss F33 10x10-ft Triangle Goal Post System! It’s not just a truss—it’s a showcase of strength, elegance, and versatility, ready to hold up your lights, speakers, screens, or banners and elevate your event to the next level.

Whether you’re a DJ spinning under the spotlight, a production manager running a trade show booth, or part of an expo team looking to make an unforgettable entrance display, this setup will ensure your event looks sharp and professional.

So, what are you waiting for? Get your Global Truss system today from famousstages.com and take your events to new heights!

Why Choose Global Truss?

• Durability: Made with high-quality aluminum, these trusses can withstand the rigors of any event, indoor or outdoor.
• Lightweight yet Strong: Despite their strength, Global Truss systems are lightweight and easy to transport.
• Versatility: From trade shows to DJ setups, stage performances to lighting rigs, Global Truss systems adapt to any environment.
• Customization: With a wide variety of shapes and sizes, you can create the perfect setup for your unique needs.

Invest in a Global Truss F33 Goal Post System, and make your next event one for the books!

Welcome to the wonderful world of stage trussing, where engineering meets art to create eye-catching, structurally sound display booths. Today, we’re setting up a Global Truss 10' x 20' Display Booth Truss  System with a center beam—ideal for any trade show or event space that demands attention. Let’s dive in!

The Key Players: Your Trussing Essentials

To build this 10' x 20' beauty, we’ll be using the following materials:

• 4 x Global Truss F34 Box Truss 8.2 ft long (for vertical posts)
• 2 x Global Truss F34 Box Truss 7.38 ft long (for horizontal width)
• 1 x Global Truss F34 Box Truss 7.38 ft long (for the center beam)
• 4 x Global Truss F34 Box Truss 8.2 ft long (for horizontal length)
• 6 x Global Truss F34 ST-UJB-12 Junction Blocks (for corners and middle connectors)
• 4 x Global Truss F34 Box Truss SQ-4137 Base Plates (for a solid foundation)

With these products from famousstages.com, you’re all set to construct a lightweight, durable display booth that’ll turn heads and boost your event presence!

Step 1: Lay the Foundation

The first step is all about creating a sturdy base. Start by placing the 4 SQ-4137 Base Plates at the corners of your 10' x 20' booth area. These base plates will keep your vertical posts secure and grounded.

Next, grab your 8.2 ft F34 Box Truss pieces and slot them into the base plates to form the vertical posts. These will give your booth its height and form the backbone of the structure. Tighten all connections so these posts stand tall and steady.

Step 2: Assembling the Top Horizontal Trusses

Now comes the fun part—building the top structure. This part is crucial for both stability and style, so let’s get it right.

The Long Sides (20 feet):

You’ll use two 8.2 ft F34 Box Truss pieces on each side of the booth. Here’s how you’ll connect them:

• Connect the two 8.2 ft F34 Box Truss pieces using a Global Truss F34 ST-UJB-12 Junction Block at the middle point.
• Attach a ST-UJB-12 junction block at each end to connect the trusses to the vertical posts.

By the end of this step, you’ll have two long sides, each composed of two 8.2 ft trusses, with ST-UJB-12 junction blocks at both ends and in the middle where the trusses meet. This gives your booth a solid 20-foot length on both sides.

The Short Sides (10 feet):

For the front and back, use the 7.38 ft F34 Box Truss pieces. Connect each end of these trusses to the ST-UJB-12 Junction Blocks at the corners of your long sides, forming the 10-foot width. These short sides complete the rectangular frame of the top.

Step 3: The Center Beam for Extra Support

Now, it’s time to add the center beam. This beam will not only add an extra layer of stability but will also give your booth a stylish, modern look.

• Use the final 7.38 ft F34 Box Truss for the center beam. Connect each end to the ST-UJB-12 Junction Blocks in the middle of the long sides. This will split the roof structure evenly down the middle, adding extra strength and allowing for more lighting or hanging banners if needed.

With the center beam in place, your top truss structure is complete. It should now resemble a sleek, rectangular frame with a central support running down the middle.

Step 4: Final Touches and Adjustments

Before you stand back to admire your work, give everything a final check. Ensure all junction blocks are securely tightened, the trusses are firmly connected, and the base plates are stable.

Now that your booth frame is fully assembled, you can start adding any extras—like lighting trusses, display banners, or multimedia screens. With the Global Truss system, you’ve got a booth that’s strong, lightweight, and incredibly versatile for whatever you need to show off at your next trade show or expo.

Why You’ll Love This Setup

The Global Truss 10' x 20' Display Booth is the ideal solution for anyone in need of a professional, sleek, and portable exhibit. Whether you’re setting up for a trade show booth, an expo trade show display, or even a home show booth, this system is designed to make a big impression.

Plus, it’s built with high-quality, lightweight aluminum trussing, so it’s easy to transport and even easier to assemble. Add in the fact that it can support everything from DJ lighting to conference displays, and you’ve got a booth that does it all.

Time to Shine

Ready to make your booth the talk of the event? With this setup from famousstages.com, you’ll not only stand out—you’ll be the centerpiece! Whether you need global truss systems, lighting trussing, or expo booths, we’ve got everything you need to succeed. So go ahead, light up that DJ truss, hang your banners, and get ready to shine!

A well-designed trade show booth is key to attracting attention at events, and the Global Truss 16x15x10 ft Trade Show Booth Display System offers a sleek and professional setup that fits perfectly within your stage trussing needs. Follow this guide to construct the system using premium trussing components.

Materials You'll Need:

• 4 pcs. Global Truss SQ-4113 F34 12-inch Aluminum Box Truss (8.20 ft) – Vertical Posts (1, 2, 3, and 4)
• 4 pcs. - 2 pcs. Global Truss SQ-4112 F34 12-inch Aluminum Box Truss (6.56 ft) – Vertical Posts (5 and 6), 2 pcs for top horizontal trusses
• 4 pcs. Global Truss SQ-4121 F34 12-inch 2-way 90-degree Corner (1.64 ft) – For base connectors of Posts 5 and 6 and center counter beam connections
• 6 pcs. Global Truss SQ-4121-CR-L90 1.64 ft Rounded 2-way Truss Corner
• 2 pcs. Global Truss SQ-4126-CR-L90 3-way 90-degree Rounded Truss Corner
• 2 pcs. Global Truss SQ-4111 F34 12-inch Aluminum Box Truss (4.92 ft)
• 2 pcs. Global Truss SQ-4110-875 F34 12-inch Aluminum Box Truss (2.87 ft)
• 2 pcs. Global Truss SQ-4109-.29 F34 12-inch Aluminum Box Truss (0.95 ft)
• 1 pcs. Global Truss SQ-4109 F34 12-inch Aluminum Box Truss (1.64 ft) – Center beam
• 4 pcs. Global Truss SQ-4137 Base Plate 12x12-inch for F34 Square Truss

Step-by-Step Assembly Instructions:

1. Setting the Foundation:

Begin by placing the base plates at each corner of your 16x15 ft space to establish the main frame. Attach the Global Truss SQ-4113 F34 12-inch Aluminum Box Trusses (8.20 ft) to the base plates, forming Posts 1, 2, 3, and 4 as your vertical support structure. These trusses are essential in stage trussing setups for providing a solid foundation.

For Posts 5 and 6 (positioned 6 feet from the back corners), you’ll need to connect Global Truss SQ-4112 F34 12-inch Aluminum Box Trusses (6.56 ft) to Global Truss SQ-4121 F34 12-inch 2-way 90-degree Corners (1.64 ft) at the base. These corners serve as foundational base connectors for the middle vertical posts, enhancing the booth’s overall stability, which is crucial in stage trussing designs.

2. Assembling the Top Horizontal Structure:

Move on to creating the top horizontal trusses. On the left side, connect a Global Truss SQ-4111 F34 12-inch Aluminum Box Truss (4.92 ft) with a Global Truss SQ-4112 F34 12-inch Aluminum Box Truss (6.56 ft). These trusses will span between Post 1 and Post 3. At the top of Post 1, attach a Global Truss SQ-4121-CR-L90 1.64 ft Rounded 2-way Truss Corner, and at the top of Post 3, connect a Global Truss SQ-4126-CR-L90 3-way 90-degree Rounded Truss Corner.

Repeat this process on the right side of the booth, connecting similar trusses between Post 2 and Post 4. The robust top horizontal structure is an essential feature of stage trussing, as it allows for hanging lighting, signage, and more, contributing to the versatility of the setup.

3. Connecting the Back Horizontal Trusses:

Next, assemble the back horizontal structure. Attach a Global Truss SQ-4110-875 F34 12-inch Aluminum Box Truss (2.87 ft) between Post 3 and Post 5 using the 3-way and 2-way corners on top of each post. On the opposite side, connect Post 4 and Post 6 with another SQ-4110-875 F34 12-inch truss, completing the rectangular top structure. This configuration provides a stable framework essential for stage trussing systems.

4. Building the Middle Counter Structure:

To form the middle counter, begin by attaching the Global Truss SQ-4109-.29 F34 12-inch Aluminum Box Trusses (0.95 ft) to the SQ-4121 F34 12-inch 2-way 90-degree Corners at the base of Post 5 and Post 6. These corners provide a stable base connection for the middle structure. The middle counter feature is a useful addition in trade show setups, where it can be used for product displays or as a support for multimedia installations.

Next, attach SQ-4121-CR-L90 1.64 ft Rounded 2-way Truss Corners horizontally to the front ends of both SQ-4109-.29 F34 12-inch Trusses at the base of Post 5 and Post 6.

For the upper center counter beam, connect a Global Truss SQ-4109 F34 12-inch Aluminum Box Truss (1.64 ft) between the two Global Truss SQ-4121 F34 12-inch 2-way 90-degree Corners (1.64 ft). Then, connect this from the vertical ends of Global Truss SQ-4121-CR-L90 1.64 ft Rounded 2-way Truss Corners, completing the middle counter section. The base structure and center beam will now be secured between Post 5 and Post 6.

Final Adjustments:

Once all components are in place, ensure the system is stable and ready to support any additional stage trussing elements like lighting, signage, or other display components. Double-check that all the truss connections are securely tightened and aligned for a polished, professional finish.

Conclusion:

The Global Truss 16x15x10 ft Trade Show Booth Display System is an exceptional solution for businesses looking to create a lasting impression at trade shows. Whether you're incorporating lighting trussing, stage trussing, or multimedia displays, this system offers the durability and flexibility you need for an eye-catching booth. Its strong framework, built with high-quality stage trussing materials, ensures that your display will stand out at any event.

Explore famousstages.com for the best deals on all the truss materials used in this guide, and build your next stage trussing system with confidence!
